Stainless steel 304 two-piece ball valve Q11F-16P all-through ball valve large flow thread thread medium thickening valve switch
304 stainless steel ball valve one-piece ball valve with internal thread manual valve Water valve switch Q11F-16P
304/201 screw screw horizontal check valve H14W check one-way return valve manufacturer direct
Stainless steel ball valve inner thread screw valve half steel/all steel water valve switch 4 minutes 6 minutes 1 inch factory direct sales
Guanwang Valve Company is an enterprise focusing on the design, manufacture and sale of stainless steel valves and piping systems. We are committed to providing customers with high-quality, reliable products to meet various industrial, commercial and personal needs.
More+
We always adhere to the "quality first, honest service" as the business purpose, strictly implement the "high quality, high standard, high precision, zero defects" policy service new and old customers.
If the product is in stock, send the picture of the product to the customer according to the customer's needs, confirm the size, material, surface treatment and mathematics, and make the quotation.
05
2025.06
Ball valve and gate valve are the same type of valve, the difference is that its closing part is a ball, the ball is rotated around the body core line to achieve the opening and closing of a valve. Ball valves are mainly used to cut off, distribute and change the flow direction of the medium in the pipeline. Flange ball valve standard GB/T21465-2008 "Valve terminology" is defined as: the opening and closing parts (spheres) are driven by the valve stem and rotate around the axis of the valve stem.
05
2025.06
Opening procedure
1. In the closed position, the ball is pressed against the seat by the mechanical pressure of the valve stem.
2. When the handwheel is turned counterclockwise, the valve stem moves in reverse, and its bottom angular plane makes the ball free from the seat.
3. The valve stem continues to lift and interact with the guide pin in the spiral groove of the valve stem so that the ball begins to rotate without friction.
4. Until it reaches the full open position, the valve stem is raised to the limit position, and the ball is rotated to the full open position.
